数字晶体管

Digital Transistor

数字晶体管，英文名为Bias Resistor Transistor，是带电阻的晶体管，有的仅在基极上串联一只电阻，一般称为R1，有的在基极与发射极之间还并联一只电阻R2。电阻R1有多种电阻，类似标准电阻系列配制，电阻R2情况类似R1。电阻R1与电阻R2可按多种方式搭配，因此数字晶体管的品种很多。

Part Number	Download	Polarity	Pc	Io	VCC	Gi	Vo(on)	R1	R2	Package
Part Number	Download	Polarity		(mA)	(V)	Gi	(V)	(Ω)	(Ω)	Package
DTA143TUA	DTAXXXTUA R1 SOT-323.pdf	PNP	200	100	50	100	0.3	4.7K+	Infinity	SOT-323
DTA143TSA		PNP	300	100	50	100	0.3	4.7K+	Infinity	TO-92S
DTA143TM		PNP	100	100	50	100	0.3	4.7K+	Infinity	SOT-723
DTA143TKA		PNP	200	100	50	100	0.3	4.7K+	Infinity	SOT-23-3L
DTA143TE	DTAXXXTE R1 SOT-523.pdf	PNP	150	100	50	100	0.3	4.7K+	Infinity	SOT-523
DTA144EUA	DTAXXXEUA R1=R2 SOT-323.pdf	PNP	200	30	50	68	0.3	47K+	47K+	SOT-323
DTA143ZKA		PNP	200	100	50	80	0.3	4.7K+	47K+	SOT-23-3L
DTA144EM		PNP	100	30	50	68	0.3	47K+	47K+	SOT-723
DTA143ZE		PNP	150	100	50	80	0.3	4.7K+	47K+	SOT-523
DTA144EKA		PNP	200	30	50	68	0.3	47K+	47K+	SOT-23-3L
DTA143ZCA	DTA143ZCA SOT-23.pd	PNP	200	100	50	80	0.3	4.7K+	47K+	SOT-23
DTA143XUA	DTAXXXXUA R1#R2 SOT-323.pd	PNP	200	100	50	30	0.3	4.7K+	10K+	SOT-323
DTA144EE	DTAXXXEE R1=R2 SOT-523.pd	PNP	150	30	50	68	0.3	47K+	47K+	SOT-523
DTA143XSA		PNP	300	100	50	30	0.3	4.7K+	10K+	TO-92S
DTA144ECA	DTAXXXECA R1=R2 SOT-23.pd	PNP	200	30	50	68	0.3	47K+	47K+	SOT-23
DTA143XM		PNP	100	100	50	30	0.3	4.7K+	10K+	SOT-723
DTA143ZUA		PNP	200	100	50	80	0.3	4.7K+	47K+	SOT-323
DTA143XKA		PNP	200	100	50	30	0.3	4.7K+	10K+	SOT-23-3L
DTA143ZSA		PNP	300	100	50	80	0.3	4.7K+	47K+	TO-92S
DTA143XE	DTAXXXXE R1#R2 SOT-523.pd	PNP	150	100	50	30	0.3	4.7K+	10K+	SOT-523
DTA143ZM		PNP	100	100	50	80	0.3	4.7K+	47K+	SOT-723
DTA143XCA	DTAXXXXCA R1#R2 SOT-23.pd	PNP	200	100	50	30	0.3	4.7K+	10K+	SOT-23
DTC114EUA	DTCXXXEUA R1=R2 SOT-323.pd	NPN	200	50	50	30	0.3	10K+	10K+	SOT-323
DTC114ESA		NPN	300	50	50	30	0.3	10K+	10K+	TO-92S
DTC115EM		NPN	100	100	50	82	0.3	100K+	100K+	SOT-723
DTC114EM		NPN	100	50	50	30	0.3	10K+	10K+	SOT-723
DTC114EKA		NPN	200	50	50	30	0.3	10K+	10K+	SOT-23-3L
DTC115EE	DTCXXXEE R1=R2 SOT-523.pd	NPN	150	100	50	82	0.3	100K+	100K+	SOT-523
DTC114EE	DTCXXXEE R1=R2 SOT-523.pd	NPN	150	50	50	30	0.3	10K+	10K+	SOT-523
DTC114YUA		NPN	200	70	50	68	0.3	10K+	47K+	SOT-323
DTC114ECA	DTCXXXECA R1=R2 SOT-23.pd	NPN	200	50	50	30	0.3	10K+	10K+	SOT-23
DTC114YSA		NPN	300	70	50	68	0.3	10K+	47K+	TO-92S
DTC113ZVA		NPN	625	100	50	33	0.3	1K+	10K+	TO-92
DTC114YM		NPN	100	70	50	68	0.3	10K+	47K+	SOT-723
DTC114YKA		NPN	200	70	50	68	0.3	10K+	47K+	SOT-23-3L
DTC113ZUA		NPN	200	100	50	33	0.3	1K+	10K+	SOT-323
DTC114YE		NPN	150	70	50	68	0.3	10K+	47K+	SOT-523
DTC113ZSA		NPN	300	100	50	33	0.3	1K+	10K+	TO-92S
DTC114YCA	DTC114YCA SOT-23.pd	NPN	200	70	50	68	0.3	10K+	47K+	SOT-23
DTC113ZM		NPN	100	100	50	33	0.3	1K+	10K+	SOT-723
DTC113ZKA		NPN	200	100	50	33	0.3	1K+	10K+	SOT-23-3L
DTC114WUA		NPN	200	100	50	24	0.3	10K+	4.7K+	SOT-323
DTC113ZE		NPN	150	100	50	33	0.3	1K+	10K+	SOT-523
DTC113ZCA	DTC113ZCA SOT-23.pd	NPN	200	100	50	33	0.3	1K+	10K+	SOT-23
DTC114WSA		NPN	300	100	50	24	0.3	10K+	4.7K+	TO-92S
DTC114WM		NPN	100	100	50	24	0.3	10K+	4.7K+	SOT-723
DTC114WKA		NPN	200	100	50	24	0.3	10K+	4.7K+	SOT-23-3L
DTA144TUA	DTAXXXTUA R1 SOT-323.pd	PNP	200	100	50	100	0.3	47K+	Infinity	SOT-323
DTA144TSA		PNP	300	100	50	100	0.3	47K+	Infinity	TO-92S
DTC114WE		NPN	150	100	50	24	0.3	10K+	4.7K+	SOT-523
DTC114WCA	DTC114WCA SOT-23.pd	NPN	200	100	50	24	0.3	10K+	4.7K+	SOT-23
DTC114TUA	DTCXXXTUA R1 SOT-323.pd	NPN	200	100	50	100	0.3	10K+	Infinity	SOT-323
DTC114TSA		NPN	300	100	50	100	0.3	10K+	Infinity	TO-92S
DTC114TM		NPN	100	100	50	100	0.3	10K+	Infinity	SOT-723
DTC114TKA		NPN	200	100	50	100	0.3	10K+	Infinity	SOT-23-3L
DTA144TM		PNP	100	100	50	100	0.3	47K+	Infinity	SOT-723
DTC114TE	DTCXXXTE R1 SOT-523.pd	NPN	150	100	50	100	0.3	10K+	Infinity	SOT-523
DTA144TKA		PNP	200	100	50	100	0.3	47K+	Infinity	SOT-23-3L
DTA144TE	DTAXXXTE R1 SOT-523.pd	PNP	150	100	50	100	0.3	47K+	Infinity	SOT-523
DTC114TCA	DTCXXXTCA R1 SOT-23.pd	NPN	200	100	50	100	0.3	10K+	Infinity	SOT-23
DTA144TCA	DTAXXXTCA R1 SOT-23.pd	PNP	200	100	50	100	0.3	47K+	Infinity	SOT-23
DTA123YKA		PNP	200	100	50	33	0.3	2.2K+	10K+	SOT-23-3L
DTA123YE		PNP	150	100	50	33	0.3	2.2K+	10K+	SOT-523
DTA123YCA	DTA123YCA SOT-23.pd	PNP	200	100	50	33	0.3	2.2K+	10K+	SOT-23
DTA123JUA		PNP	200	100	50	80	0.3	2.2K+	47K+	SOT-323
DTC144TUA	DTCXXXTUA R1 SOT-323.pd	NPN	200	100	50	100	0.3	47K+	Infinity	SOT-323
DTA123JSA		PNP	300	100	50	80	0.3	2.2K+	47K+	TO-92S
DTC144TSA		NPN	300	100	50	100	0.3	47K+	Infinity	TO-92S
DTA123JM		PNP	100	100	50	80	0.3	2.2K+	47K+	SOT-723
DTC144TM		NPN	100	100	50	100	0.3	47K+	Infinity	SOT-723
DTA123JKA		PNP	200	100	50	80	0.3	2.2K+	47K+	SOT-23-3L
DTC144TKA		NPN	200	100	50	100	0.3	47k+	Infinity	SOT-23-3L
DTA123JE		PNP	150	100	50	80	0.3	2.2K+	47K+	SOT-523
DTA123JCA	DTA123JCA SOT-23.pd	PNP	200	100	50	80	0.3	2.2K+	47K+	SOT-23
DTC144TE	DTCXXXTE R1 SOT-523.pd	NPN	150	100	50	100	0.3	47K+	Infinity	SOT-523
DTC144TCA	DTCXXXTCA R1 SOT-23.pd	NPN	200	100	50	100	0.3	47K+	Infinity	SOT-23
DTA115TUA	DTAXXXTUA R1 SOT-323.pd	PNP	200	100	50	100	0.3	100K+	Infinity	SOT-323
DTC144EUA	DTCXXXEUA R1=R2 SOT-323.pd	NPN	200	30	50	68	0.3	47K+	47K+	SOT-323
DTC144ESA		NPN	300	30	50	68	0.3	47K+	47K+	TO-92S
DTA115TSA		PNP	300	100	50	100	0.3	100K+	Infinity	TO-92S
DTC144EM		NPN	100	30	50	68	0.3	47K+	47K+	SOT-723
DTC144EKA		NPN	200	30	50	68	0.3	47K+	47K+	SOT-23-3L
DTA115TM		PNP	100	100	50	100	0.3	100K+	Infinity	SOT-723
DTC144EE	DTCXXXEE R1=R2 SOT-523.pd	NPN	150	30	50	68	0.3	47K+	47K+	SOT-523
DTC144ECA	DTCXXXECA R1=R2 SOT-23.pd	NPN	200	30	50	68	0.3	47K+	47K+	SOT-23
DTA115TKA		PNP	200	100	50	100	0.3	100K+	Infinity	SOT-23-3L
DTC143ZUA		NPN	200	100	50	80	0.3	4.7K+	47K+	SOT-323
DTA115TE	DTAXXXTE R1 SOT-523.pd	PNP	150	100	50	100	0.3	100K+	Infinity	SOT-523
DTC143ZSA		NPN	300	100	50	80	0.3	4.7K+	47K+	TO-92S
DTC143ZM		NPN	100	100	50	80	0.3	4.7K+	47K+	SOT-723
DTA115TCA	DTAXXXTCA R1 SOT-23.pd	PNP	200	100	50	100	0.3	100K+	Infinity	SOT-23
DTA114YUA		PNP	200	70	50	68	0.3	10K+	47K+	SOT-323
DTA114YSA		PNP	300	70	50	68	0.3	10K+	47K+	TO-92S
DTC143ZKA		NPN	200	100	50	80	0.3	4.7K+	47K+	SOT-23-3L
DTA114YM		PNP	100	70	50	68	0.3	10K+	47K+	SOT-723
DTC143ZE		NPN	150	100	50	80	0.3	4.7K+	47K+	SOT-523
DTA114YKA		PNP	200	70	50	68	0.3	10K+	47K+	SOT-23-3L
DTC143ZCA	DTC143ZCA SOT-23.pd	NPN	200	100	50	80	0.3	4.7K+	47K+	SOT-23
DTA114YE		PNP	150	70	50	68	0.3	10K+	47K+	SOT-523
DTA114YCA	DTA114YCA SOT-23.pd	PNP	200	70	50	68	0.3	10K+	47K+	SOT-23
DTA114TUA	DTAXXXTUA R1 SOT-323.pd	PNP	200	100	50	100	0.3	10K+	Infinity	SOT-323
DTA114TSA		PNP	300	100	50	100	0.3	10K+	Infinity	TO-92S
DTC143XUA		NPN	200	100	50	30	0.3	4.7K+	10K+	SOT-323
DTA114TM		PNP	100	100	50	100	0.3	10K+	Infinity	SOT-723
DTC143XSA		NPN	300	100	50	30	0.3	4.7K+	10K+	TO-92S
DTC143XM		NPN	100	100	50	30	0.3	4.7K+	10K+	SOT-723
DTA114TKA		PNP	200	100	50	100	0.3	10K+	Infinity	SOT-23-3L
DTA114TE	DTAXXXTE R1 SOT-523.pd	PNP	150	100	50	100	0.3	10K+	Infinity	SOT-523
DTA114TCA	DTAXXXTCA R1 SOT-23.pd	PNP	200	100	50	100	0.3	10K+	Infinity	SOT-23
DTC143XKA		NPN	200	100	50	30	0.3	4.7K+	10K+	SOT-23-3L
DTC143XE		NPN	150	100	50	30	0.3	4.7K+	10K+	SOT-523
DTC143XCA	DTCXXXXCA R1#R2 SOT-23.pd	NPN	200	100	50	30	0.3	4.7K+	10K+	SOT-23
DTC143TUA	DTCXXXTUA R1 SOT-323.pd	NPN	200	100	50	100	0.3	4.7K+	Infinity	SOT-323
DTC143TSA		NPN	300	100	50	100	0.3	4.7K+	Infinity	TO-92S
DTC143TM		NPN	100	100	50	100	0.3	4.7K+	Infinity	SOT-723
DTC143TKA		NPN	200	100	50	100	0.3	4.7K+	Infinity	SOT-23-3L
DTC143TE	DTCXXXTE R1 SOT-523.pd	NPN	150	100	50	100	0.3	4.7K+	Infinity	SOT-523
DTC143TCA	DTCXXXTCA R1 SOT-23.pd	NPN	200	100	50	100	0.3	4.7K+	Infinity	SOT-23
DTC143EUA	DTCXXXEUA R1=R2 SOT-323.pd	NPN	200	100	50	20	0.3	4.7K+	4.7K+	SOT-323
DTC143ESA		NPN	300	100	50	20	0.3	4.7K+	4.7K+	TO-92S
DTC143EM		NPN	100	100	50	20	0.3	4.7K+	4.7K+	SOT-723
DTC143EKA		NPN	200	100	50	20	0.3	4.7K+	4.7K+	SOT-23-3L
DTC143EE	DTCXXXEE R1=R2 SOT-523.pd	NPN	150	100	50	20	0.3	4.7K+	4.7K+	SOT-523
DTC143ECA	DTCXXXECA R1=R2 SOT-23.pd	NPN	200	100	50	20	0.3	4.7K+	4.7K+	SOT-23
DTC124TCA	DTCXXXTCA R1 SOT-23.pd	NPN	200	100	50	100	0.3	22K+	Infinity	SOT-23
DTA114EUA	DTAXXXEUA R1=R2 SOT-323.pd	PNP	200	50	50	30	0.3	10K+	10K+	SOT-323
DTC124EUA	DTCXXXEUA R1=R2 SOT-323.pd	NPN	200	30	50	56	0.3	22K+	22K+	SOT-323
DTA114ESA		PNP	300	50	50	30	0.3	10K+	10K+	TO-92S
DTC124ESA		NPN	300	30	50	56	0.3	22K+	22K+	TO-92S
DTA114EM		PNP	100	50	50	30	0.3	10K+	10K+	SOT-723
DTC124EM		NPN	100	30	50	56	0.3	22K+	22K+	SOT-723
DTA114EKA		PNP	200	50	50	30	0.3	10K+	10K+	SOT-23-3L
DTC124EKA		NPN	200	30	50	56	0.3	22K+	22K+	SOT-23-3L
DTC124EE	DTCXXXEE R1=R2 SOT-523.pd	NPN	150	30	50	56	0.3	22K+	22K+	SOT-523
DTC124ECA	DTC124ECA SOT-23.pd	NPN	200	30	50	56	0.3	22K+	22K+	SOT-23
DTA114EE	DTAXXXEE R1=R2 SOT-523.pd	PNP	150	50	50	30	0.3	10K+	10K+	SOT-523
DTC123YUA		NPN	200	100	50	33	0.3	2.2K+	10K+	SOT-323
DTA114ECA	DTAXXXECA R1=R2 SOT-23.pd	PNP	200	50	50	30	0.3	10K+	10K+	SOT-23
DTC123YSA		NPN	300	100	50	33	0.3	2.2K+	10K+	TO-92S
DTC123YM		NPN	100	100	50	33	0.3	2.2K+	10K+	SOT-723
DTA113ZVA		PNP	625	100	50	33	0.3	1K+	10K+	TO-92
DTC123YKA		NPN	200	100	50	33	0.3	2.2K+	10K+	SOT-23-3L
DTA113ZUA		PNP	200	100	50	33	0.3	1K+	10K+	SOT-323
DTC123YE		NPN	150	100	50	33	0.3	2.2K+	10K+	SOT-523
DTC123YCA	DTC123YCA SOT-23.pd	NPN	200	100	50	33	0.3	2.2K+	10K+	SOT-23
DTC123JUA		NPN	200	100	50	80	0.3	2.2K+	47K+	SOT-323
DTC123JSA		NPN	300	100	50	80	0.3	2.2K+	47K+	TO-92S
DTA113ZSA		PNP	300	100	50	33	0.3	1K+	10K+	TO-92S
DTC123JM		NPN	100	100	50	80	0.3	2.2K+	47K+	SOT-723
DTA113ZM		PNP	100	100	50	33	0.3	1K+	10K+	SOT-723
DTC123JKA		NPN	200	100	50	80	0.3	2.2K+	47K+	SOT-23-3L
DTA113ZKA		PNP	200	100	50	33	0.3	1K+	10K+	SOT-23-3L
DTC123JE		NPN	150	100	50	80	0.3	2.2K+	47K+	SOT-523
DTA113ZE		PNP	150	100	50	33	0.3	1K+	10K+	SOT-523
DTC123JCA		NPN	200	100	50	80	0.3	2.2K+	47K+	SOT-23
DTC123EUA	DTCXXXEUA R1=R2 SOT-323.pd	NPN	200	100	50	20	0.3	2.2K+	2.2K+	SOT-323
DTC123ESA		NPN	300	100	50	20	0.3	2.2K+	2.2K+	TO-92S
DTC123EM		NPN	100	100	50	20	0.3	2.2K+	2.2K+	SOT-723
DTA113ZCA	DTA113ZCA SOT-23.pd	PNP	200	100	50	33	0.3	1K+	10K+	SOT-23
DTC123EKA		NPN	200	100	50	20	0.3	2.2K+	2.2K+	SOT-23-3L
DTC123EE	DTCXXXEE R1=R2 SOT-523.pd	NPN	150	100	50	20	0.3	2.2K+	2.2K+	SOT-523
DTC123ECA	DTCXXXECA R1=R2 SOT-23.pd	NPN	200	100	50	20	0.3	2.2K+	2.2K+	SOT-23
DTA123YM		PNP	100	100	50	33	0.3	2.2K+	10K+	SOT-723
DTA124EKA		PNP	200	30	50	56	0.3	22K+	22K+	SOT-23-3L
DTA123YSA		PNP	300	100	50	33	0.3	2.2K+	10K+	TO-92S
DTA123YUA		PNP	200	100	50	33	0.3	2.2K+	10K+	SOT-323
DTA124ECA	DTAXXXECA R1=R2 SOT-23.pd	PNP	200	30	50	56	0.3	22K+	22K+	SOT-23
DTA124EE	DTAXXXEE R1=R2 SOT-523.pd	PNP	150	30	50	56	0.3	22K+	22K+	SOT-523
DTA124EM		PNP	100	30	50	56	0.3	22K+	22K+	SOT-723
DTA124ESA		PNP	300	30	50	56	0.3	22K+	22K+	TO-92S
DTA124EUA	DTAXXXEUA R1=R2 SOT-323.pd	PNP	200	30	50	56	0.3	22K+	22K+	SOT-323
DTA124XE	DTAXXXXE R1#R2 SOT-523.pd	PNP	150	100	50	68	0.3	22K+	47K+	SOT-523
DTA143ECA	DTAXXXECA R1=R2 SOT-23.pd	PNP	200	100	50	30	0.3	4.7K+	4.7K+	SOT-23
DTA143EE	DTAXXXEE R1=R2 SOT-523.pd	PNP	150	100	50	30	0.3	4.7K+	4.7K+	SOT-523
DTA143EKA		PNP	200	100	50	30	0.3	4.7K+	4.7K+	SOT-23-3L
DTA143EM		PNP	100	100	50	30	0.3	4.7K+	4.7K+	SOT-723
DTA143ESA		PNP	300	100	50	30	0.3	4.7K+	4.7K+	TO-92S
DTA143EUA	DTAXXXEUA R1=R2 SOT-323.pd	PNP	200	100	50	30	0.3	4.7K+	4.7K+	SOT-323
DTA143TCA	DTAXXXTCA R1 SOT-23.pd	PNP	200	100	50	100	0.3	4.7K+	Infinty	SOT-23
DTA115EM		PNP	100	-100	-50	82	-0.3	100K+	100K+	SOT-723
DTA115EE	DTAXXXEE R1=R2 SOT-523.pd	PNP	150	-100	-50	82	-0.3	100K+	100K+	SOT-523
DTA115ECA	DTAXXXECA R1=R2 SOT-23.pd	PNP	200	-100	-50	82	-0.3	100K+	100K+	SOT-23
